BoltBait's Meme Maker v1.3 - Aug 21, 2016

[BoltBait]

BoltBait's Meme Maker

Plugin v1.3





If you are using Paint.NET v3.5.11, Download here:

 MemeMaker13.zip (v1.3) Unzip this to your desktop and run the Install_MemeMaker.BAT file to install.



If you are using paint.net v4.0.6+, Download here:

 BoltBait's Plugin Pack for paint.net v4.0.6+ (v1.3 with Shadow option)





Once installed, you'll find this under the Effects > Photo > Meme Maker menu.



Requirements:

- Paint.NET 3.5.11 or higher

- The font "IMPACT" must be installed on your system.  It probably is as it comes standard with Windows.



Versions:

-1.3 Added shadow option

-1.2 Fixed a bug when centering in a selection

-1.1 Added separate size for each text, Added ability to use Primary/Secondary colors

-1.0 Initial Release



CodeLab source for v1.2



Spoiler

// Name: Meme Maker
// Submenu: Photo
// Author: BoltBait
// Title: BoltBait's Meme Maker v1.2
// Version: 1.2
// Desc: Create your own memes
// Keywords: text|meme
// URL: http://BoltBait.com/pdn
#region UICode
string Amount1 = ""; // [1,32767] Top Text
int Amount2 = 36; // [10,100] Size
string Amount3 = ""; // [1,32767] Bottom Text
int Amount4 = 36; // [10,100] Size
bool Amount5 = true; // [0,1] ALL CAPS
bool Amount6 = true; // [0,1] Centered
bool Amount7 = false; // [0,1] Use Primary/Secondary Colors
bool Amount8 = false; // [0,1] Swap Colors
#endregion

void Render(Surface dst, Surface src, Rectangle rect)
{
    Rectangle selection = EnvironmentParameters.GetSelection(src.Bounds).GetBoundsInt();
    dst.CopySurface(src,rect.Location,rect);
    if (IsCancelRequested) return;
    ColorBgra PrimaryColor = (ColorBgra)EnvironmentParameters.PrimaryColor;
    ColorBgra SecondaryColor = (ColorBgra)EnvironmentParameters.SecondaryColor;

    int tfs = Amount2;
    float tos = tfs / 10f;
    int bfs = Amount4;
    float bos = bfs / 10f;

    SolidBrush Brush1 = new SolidBrush(Color.Black);
    SolidBrush Brush2 = new SolidBrush(Color.White);

    if (Amount8)
    {
        Brush1 = new SolidBrush(Color.White);
        Brush2 = new SolidBrush(Color.Black);
    }

    if (Amount7)
    {
        if (Amount8)
        {
            Brush1 = new SolidBrush(SecondaryColor);
            Brush2 = new SolidBrush(PrimaryColor);
        }
        else
        {
            Brush1 = new SolidBrush(PrimaryColor);
            Brush2 = new SolidBrush(SecondaryColor);
        }
    }

    Graphics g = new RenderArgs(dst).Graphics;
    g.Clip = new Region(rect);
    g.SmoothingMode = System.Drawing.Drawing2D.SmoothingMode.AntiAlias;
    Font SelectedFont = new Font("Impact", bfs);

    string TopText = Amount1;
    if (Amount5) TopText = TopText.ToUpper();
    string BottomText = Amount3;
    if (Amount5) BottomText = BottomText.ToUpper();

    SizeF stringSize = new SizeF();
    stringSize = g.MeasureString(BottomText, SelectedFont);

    int TopX = selection.Left;
    int TopY = selection.Top;
    int BottomY = (int)(selection.Bottom - stringSize.Height);

    StringFormat sf = new StringFormat();
    if (Amount6)
    {
        sf.Alignment = StringAlignment.Center;
        TopX = (int)(selection.Width / 2 + selection.Left);
    }

    System.Drawing.Drawing2D.GraphicsPath p = new System.Drawing.Drawing2D.GraphicsPath();
    Pen tpn = new Pen(Brush1, tos);
    tpn.LineJoin = System.Drawing.Drawing2D.LineJoin.Round;
    Pen bpn = new Pen(Brush1, bos);
    bpn.LineJoin = System.Drawing.Drawing2D.LineJoin.Round;

    // Top Text
    p.AddString(TopText,new FontFamily("Impact"),(int) System.Drawing.FontStyle.Regular,g.DpiY * tfs / 72,new System.Drawing.Point(TopX, TopY),sf);
    g.DrawPath(tpn, p);
    g.FillPath(Brush2, p);

    // Bottom Text
    p.AddString(BottomText,new FontFamily("Impact"),(int) System.Drawing.FontStyle.Regular,g.DpiY * bfs / 72,new System.Drawing.Point(TopX, BottomY),sf);
    g.DrawPath(bpn, p);
    g.FillPath(Brush2, p);
}





[Eli]

Cool! and thanks BoltBait!

A shadow option could make the text stand out even more.

Edited August 16, 2016 by Eli

[IRON67]

44 minutes ago, Eli said:

A shadow option could make the text stand out even more.

Put it in a separate layer and use Object -> Object Shadow oder Object -> Drop Shadow.

[Eli]

3 minutes ago, IRON67 said:

Put it in a separate layer and use Object -> Object Shadow oder Object -> Drop Shadow.

That is what I usually do.



Boltbait, I know you like your interfaces as clean as possible but a color option would be nice too. Perhaps using the selected (primary and secondary) colors. I know how to colorize black and white text but for some users could be a challange.

[BoltBait]

6 hours ago, Eli said:

A shadow option could make the text stand out even more.



Put your text on it's own layer and run Effects > Object > Object Shadow



Adding that code into this plugin would be... complicated.



5 hours ago, Eli said:

I know you like your interfaces as clean as possible but a color option would be nice too.



You know me so well...



OK.  Download v1.1 in the first post.



[lynxster4]

Love it BoltBait!!  Really simplifies things.







How come my emoticons look different from everyone else's??

Okay...some are different.

Now they're not....?



Edited July 27, 2017 by lynxster4
re-hosted image

[nitenurse79]

Much fun   Thanks BoltBait

[Pixey]

Ooooo - what a FUN Plugin - thank you so much @BB .



These are of a kitty that used to visit us when we lived in Switzerland.









[Eli]

Boltbait, centered justification is not working when using a selection :

Spoiler



[BoltBait]

1 hour ago, Eli said:

Boltbait, centered justification is not working when using a selection



Thanks for the bug report.  It is fixed now.  Download v1.2 in the first post.



...and, now you know why I never put new plugins right into my plugin pack.

[Ego Eram Reputo]

^ such wisdom!

[Maximilian]

I can use this in so many ways!





[Ego Eram Reputo]

+1 if there was a way I could give you two votes I would have

[Maximilian]

Oh, thank you Ego, you're too kind!

[flaner]

no scrolling

Edited August 18, 2016 by flaner

[Seerose]

Sir BB!



Thank you for effort and this is very interesting plugin.

[BoltBait]

7 hours ago, flaner said:

no scrolling



True.  But, if you put your cursor in their, you can move around with your arrow keys.



BTW, this is not something that I have control over.  Adding a scrollbar is something Rick would have to do and it would apply to all effects that use a text control.

[BoltBait]

On 8/16/2016 at 2:31 AM, Eli said:

A shadow option could make the text stand out even more.



I just added a Shadow option.



It really makes the text pop off the screen.  Enjoy.

[Seerose]

[Maximilian]

[ingwer]

Thank you BoltBait for the Meme Maker! Unfortunately, I'm not good at writing a clever meme, but I nevertheless like your plugin.



Bolt Bait's Meme Maker on YT (German/English)

[Seerose]

@ingwer!  Thank you so much for the time to host these.  Well done.

[ingwer]

Thanks again to you, toe_head, red ochre, Remake and Seerose!

[Vagabondi]

Sorry, couldn't help...



Edited October 16, 2019 by Vagabondi
