Fractal Curly Tree (ymd: 180407)

Recommended Posts

Fractal Curly Tree









What's this?

This effect uses a fractal algorithm to draw a curly tree.

based on source code available at

http://csharphelper.com/blog/2016/02/draw-a-curly-tree-fractal-using-less-memory-in-c/



Download it!

Plugin FractalTree.dll

ar.png  Here is the DLL http://jcljay.free.fr/pdn/FractalTree.zip





The MadJik's All plugins package is available!

http://forums.getpaint.net/index.php?showtopic=7186







How to install

Close Paint.net



Classic version of Paint.net

Unzip and (re)place the DLL in your Effect folder usually:

C:/Program Files/Paint.NET/Effects (please reverse / for correct path)



Microsoft Store version of Paint.net

Unzip and (re)place the DLL in your Effect folder usually:

My Documents/paint.net App Files/Effects (please reverse / for correct path)



You have to adapt for your language My Documents





How does it work?

The effect first calculates the size of the tree and then defines a ratio to make it fit in the selection. This is why the result is always inside.





The User interface

This plugin is added to the menu Effects, submenu Render.




Level (higher = slower)

Number of levels to draw a tree. High level give more details but could take more time and CPU.



Start angle

Rotation adjustment of the tree. Default is vertical for the first segment..



Link angles (B = -A)

Check it for a symmetric tree, angle of left branches is negative angle of the right branches.



Angle A/B

Two angles adjustments for two branches at each new level.



Link length (B = A)

Check it for equal lengths between left and right branches.



Length A/B (higher = slower)

Two lengths adjustments for two branches at each new level.



Start Thickness

Adjust the thickness of the first segment. The thickness is reducing at each new level and it is adjusted by the ratio of the tree vs the canvas.



Margin

Add a margin around the tree from point to point. It doesn’t use the thickness in care to calculate the margin.



Transparency

Adapt the transparencies of the elements of the segments,



Invert horizontal/vertical

Check boxes to mirror the tree horizontally or vertically.



End caps style

Select the ends cap style of the lines.



Use full area (no aspect ratio)

The tree is placed depending on its dimensions compared with the size of canvas but keep a ratio for the aspect. Check to fill the maximum area without the aspect ratio.



Use palette of colors

By default, the tree use the color wheel (primary color). When checked, each segment use a color from the active palette.



Color

If “Use palette of colors” is unchecked, you could choose another color to draw the tree.



Add shadow

Check this to draw a dark segment before the color segment making a small relief shadow on the tree.







Examples














and with more work:








Voilà! Enjoy!



  • Like 4
  • Upvote 4

Share this post


Link to post
Share on other sites

Cool plugin @MadJik!  I did this too quickly...somehow it looks like a brain.  :lol:



There are so many variables and outcomes; I'll have to experiment more.  Thank you!!   :beer:






You da 'plugin master'!



Edited by lynxster4
  • Like 3

Share this post


Link to post
Share on other sites

Such a pretty Plugin you have made here :D






  • Like 3

Share this post


Link to post
Share on other sites
8 hours ago, MadJik said:

With indirectUI?



You would have to use Windows Forms to allow loading and saving presets.

Share this post


Link to post
Share on other sites

<3 @MadJik! Thank you so much for sharing. :coffee: :cake:

It did not work out so well with the tree.









Edited by Seerose
  • Like 3
  • Upvote 1

Share this post


Link to post
Share on other sites

I still have a little picture. That's the best I can do right now. But as feedback for the plugin creator I dare, despite the super beautiful predecessors :doh:




  • Like 3

Share this post


Link to post
Share on other sites

A round tree, a field, blue sky and a reading grandpa united in this naive picture, created in the Fractal Curly Tree, makes me really happy.  I enjoyed the many hours I spent trying!


  • Like 3
  • Upvote 1
