Spoked Wheel v1.1 (March 5, 2016)

[toe_head2001]

Spoked Wheel

Effects -> Render -> Spoked Wheel





Change Log

v1.1 (March 5, 2016)

• Changed: The range for Line Thicknesses now maxes out at 100

v1.0 (Feb 20, 2016)

• Initial release



Download

SpokedWheel.zip



Spoiler

 <---- Icon



// Name: Spoked Wheel
// Submenu: Render
// Author: toe_head2001
// Title:
// Version: 1.1
// Desc: Generates a Spoked Wheel
// Keywords:
// URL:
// Help:
#region UICode
IntSliderControl Amount1 = 5; // [3,20] Spokes
DoubleSliderControl Amount2 = 1; // [0.1,1] Wheel Size
DoubleSliderControl Amount3 = 0.333; // [0.1,0.9] Axle Size
IntSliderControl Amount4 = 2; // [1,100] Rim Thickness
ListBoxControl Amount5 = 0; // Rim Style|Solid|Dashed|Dotted
IntSliderControl Amount6 = 2; // [1,100] Spoke Thickness
ListBoxControl Amount7 = 0; // Spoke Style|Solid|Dashed|Dotted
IntSliderControl Amount8 = 2; // [1,100] Axle Thickness
ListBoxControl Amount9 = 0; // Axle Style|Solid|Dashed|Dotted
AngleControl Amount10 = 0; // [-180,180] Rotation
ColorWheelControl Amount11 = ColorBgra.FromBgr(0,0,0); // Color
#endregion

void Render(Surface dst, Surface src, Rectangle rect)
{
    Rectangle selection = EnvironmentParameters.SelectionBounds;
    float centerX = ((selection.Right - selection.Left) / 2f) + selection.Left;
    float centerY = ((selection.Bottom - selection.Top) / 2f) + selection.Top;
    float diameter = (float)Amount2 * Math.Min(selection.Width - 4, selection.Height - 4) - Amount4;
    float radius = diameter / 2f;
    float offsetX = centerX - radius;
    float offsetY = centerY - radius;
    float axleDiameter = (float)Amount3 * diameter;
    float axleOffsetX = centerX - axleDiameter / 2f;
    float axleOffsetY = centerY - axleDiameter / 2f;
    float start = (float)Amount10;
    float sweep = 360f / Amount1;

    dst.CopySurface(src, rect.Location, rect);

    using (Graphics wheel = new RenderArgs(dst).Graphics)
    {
        wheel.SmoothingMode = SmoothingMode.AntiAlias;
        wheel.Clip = new Region(rect);

        using (Pen wheelPen = new Pen(Amount11))
        {
            // Draw Rim
            wheelPen.Width = Amount4;
            wheelPen.DashStyle = getDashStyle(Amount5);
            wheel.DrawEllipse(wheelPen, offsetX, offsetY, diameter, diameter);

            // Draw Spokes
            wheelPen.Width = Amount6;
            wheelPen.DashStyle = getDashStyle(Amount7);
            for (int spoke = 0; spoke < Amount1; spoke++)
            {
                float degrees = start + sweep * spoke;
                double radians = Math.PI / 180 * degrees;

                float startX = (float)(radius * Amount3 * Math.Sin(radians));
                float startY = (float)(radius * Amount3 * Math.Cos(radians));

                float endX = (float)(radius * Math.Sin(radians));
                float endY = (float)(radius * Math.Cos(radians));

                wheel.DrawLine(wheelPen, centerX - startX, centerY - startY, centerX - endX, centerY - endY);
            }

            // Draw Axle
            wheelPen.Width = Amount8;
            wheelPen.DashStyle = getDashStyle(Amount9);
            wheel.DrawEllipse(wheelPen, axleOffsetX, axleOffsetY, axleDiameter, axleDiameter);
        }
    }
}

static DashStyle getDashStyle(byte style)
{
    DashStyle dashStyle;
    switch (style)
    {
        case 0: // Solid
            dashStyle = DashStyle.Solid;
            break;
        case 1: // Dashed
            dashStyle = DashStyle.Dash;
            break;
        case 2: // Dotted
            dashStyle = DashStyle.Dot;
            break;
        default:
            dashStyle = DashStyle.Solid;
            break;
    }
    return dashStyle;
}





[BoltBait]

You could shorten up the UI by changing those radio buttons into drop-down lists.

[toe_head2001]

You could shorten up the UI by changing those radio buttons into drop-down lists.



Dang it, I meant to change those before posting. Anyway, they're drop-down lists now.

[Eli]

Just what I needed, Thank you!



Edited February 21, 2016 by Eli

[lynxster4]

Thank you, toe_head! I'm sure I'll find a use for this...







Just what I needed, Thank you!



Space, the final frontier...





Eli, Beam me up!!          (I'm a huge Trekkie...)

[skullbonz]

Couldn't this be done with Red Ochre's Gears plugin ?

[Eli]

Hello skullbonz,



Thanks for the tip, I tried Gears and this is what I came up " Not all spoked wheels are made the same"

[toe_head2001]

Couldn't this be done with Red Ochre's Gears plugin ?



This plugin was specifically requested by @Eli.

[Eli]

Yes, the Spoked Wheel effect is designed to slice a circle into equal parts. In the example above, both have 5 spokes.

[toe_head2001]

Version 1.1 posted. The Line Thicknesses can now go up to 100.



Sorry Eli, I had this new version ready two weeks ago when you asked me about the line thickness. I simply forgot to post it.

[Eli]

Thanks toe_head2001, the adjustments work very well. The thicker lines are  large enough when working on a very large canvas.

[Maximilian]

Here's the plugin compiled for the old PdN: Spoked Wheel 1.1 for PdN 3.5.11.zip



This may be a far-fetched application, but I think this is good for creating chopped trees, or maybe circular woody mazes. Of course the spoked wheel was just the starting point after which I had to do a couple additional things, but anyway, the spoked wheel took part and that's what counts Here are two quickies whose main objects I believe resemble chopped trees (maybe the first one looks more like a circular maze http://smiles.kolobok.us/artists/just_cuz/JC_thinking.gif). Perhaps the textures can be improved.



Scene 1:



Scene 2:



Edited September 14 by Maximilian
broken pic links repaired

[Eli]

Hello @toe_head2001, the next time you update Spoked Wheel would it be possible to have more spokes?  Something like 32.   Thanks!

[toe_head2001]

6 minutes ago, Eli said:

would it be possible to have more spokes?  Something like 32.   Thanks!



There is no technical limitation, so if you want 32, just edit the source file.



Change this from:

IntSliderControl Amount1 = 5; // [3,20] Spokes

to this:

IntSliderControl Amount1 = 5; // [3,32] Spokes



[Eli]

Thank you. I will do it. ☺️ This is not a fancy effect but I find it very useful. ⭐

[Blend3rman]

This is a neat little render tool for creating spokes behind a central object. I was wondering if the spokes could be made to taper as they got closer to the axle?

[toe_head2001]

4 hours ago, Blend3rman said:

I was wondering if the spokes could be made to taper as they got closer to the axle?



Sorry, there's no easy way to do that.

[Reptillian]

28 minutes ago, toe_head2001 said:



Sorry, there's no easy way to do that.

Agreed, there is actually a theoretical way I know how to do it. But, it requires warping image assuming distance from center is y and square borders as x, then create linear stroke, and transform it back where x axis is x and y axis is y. But, that is not easy at all.



Actually maybe polar transformation would be easier to code in. A lot easier in fact.

Edited March 20, 2020 by Reptillian

[Eli]

I am not sure if this can help but @MadJik's Light Rays... makes lines go from thick to thin.

Spoiler



[Reptillian]

The thing is that it's not consistent within the spokes. That's why I suggest polar transform. Generate the outlines within pre-transform vector, then polar transform right back. But, I'm not so qualified to know c# limitation in context of paint.net, but this is indeed possible within g'mic-qt and c++ within other programs.

Edited March 20, 2020 by Reptillian

[Red ochre]

Could 'Gears' be an alternative?

[audiodane]

Thank you, @toe_head2001 for this plugin -- using it to create a challenge coin...
